Calculate your size
Help
Help
Please check height and crotch fields, only numeric values are valid
Your measurement.
Your measurements fall within both sizes indicated.
We recommend that you contact a retailer for further advice.
We recommend that you contact a retailer for further advice.
The association between anthropometric measurements (rider height/horse height) and frame size is a statistical average based on the over 17,000 tests carried out and present in the idmatch database considering the correlation between frame size - stem length. All this - given that each Cipollini® frame has a specific geometry aimed at the different use of the specific type of cyclist - has the sole purpose of providing an initial indication of the correct size to choose for the specific model. In order to fully enjoy the experience with a Cipollini® frame, we advise you to choose an "idmatch dealer" or a professional biomechanic for the correct positioning on the bike.
go back
How to measure height
Stand upright
Stand barefoot against a wall with your heels, buttocks, shoulders and head touching the wall. Straighten your chin and look straight ahead. Ask a person to place a book on your head, pushing it parallel until it touches the wall so that it creates a right angle with the wall.
At this point the person helping you will draw a line with a pencil at the level that reaches the book on the wall. Measure the distance from the floor to the line: the number obtained corresponds to your height.
go back
How to measure crotch
For the measurement you need to be barefoot and wear cycling shorts. Stand up straight against a wall and having someone help you, place a metric spirit level (bubble) between your thighs, at crotch height.
Measure the distance from the outer edge of the spirit level to the ground. This measurement corresponds to your horse
Technical features
- maximum tyre width29 mm (Larghezza Misurata)
- central movementPRESSFIT 41 x 86,5 mm
- fork weight370 g
- chassis weight780 g
- seat postOffset 10mm 100 g
- headsetConical 1.1/2” 1.1/2”
- break systemDisk brake (flat mount, thru axle 12 x 142 mm - 12 x 100 mm)
- forkMCipollini Dolomia
- seatpostMCipollini Dolomia
- chassisMCipollini Dolomia
Discover DOLOMITE in every detail
With DOLOMIA, lightness comes in a form never seen before on a road bike.
Description
DOLOMIA presents the lightest frame in the MCipollini range: 780 g for size M. The geometries designed for each size also return all the responsiveness typical of MCipollini frames, together with the perfect connection of the central motion rig. Performance is further enhanced by 3K fabric that provides the best stiffness to weight ratio achievable on carbon fibre frames. The internal cable routing, thanks to the 1' 1/2 steering series and the specific fork, guarantees maximum integration for hydraulic and electronic cabling. Overall lightness is achieved thanks to the assembly using lighter components, within the limits allowed by the UCI.
User manual
To find out all about the use and maintenance of your MCipollini DOLOMIA please refer to the manual available here.
Download
Warranty
Discover our warranty for your new MCipollini
Download
Spare parts
If you need replacement parts for your DOLOMIA see the full catalogue here.
Download
TCM, the Frame of a Genius
MCipollini’s TCM monocoque frame eliminates many of the weaknesses of the other monocoque frames on the market, which are often built by fastening the rear triangle to the front of the frame using adhesive.. This treatment makes the frame structure more prone to deterioration in the long term, resulting in a decrease in performance. TCM's monocoque structure however tends to absorb the pressures of the frame more evenly and with less impact, promoting durability over the years. Stronger, tougher, lighter: this is why the MCipollini frame is the Frame of a Genius.
How we build the TCM frame
The TCM frame created from a single mould, thanks to a long and complex machining process. The carbon elements are positioned and layered inside an aluminium mould to achieve the maximum result. This means that the lamination process produces a single piece that does not undergo any further structural processing or subsequent firing that could alter the frame structure.
Perfect fibres
The choice of the fibres used in the lamination, their certification and the autoclave construction technology bestow unique mechanical characteristics to the MCipollini frames. The materials used in the manufacturing process are pre-impregnated with epoxy matrix resins and undergo sequential checks to ensure that the resin content is uniform on all the various parts.
